Walnut Charger
1 / 5
| Parameters | Requirements | |
| General Requirements | ||
| Charger Capacity | 20KW | 30KW |
| AC Supply System | Three-Phase, 5 Wire AC system | |
| Nominal Input Voltage | AC380V±15% | |
| Ambient Temperature | -25 to 55°C | |
| IP Ratings | IP 54 | |
| Safety Parameters | Over Current, Over Voltage, Under Voltage, Residual Current, Surge Protection, Leakage Protection, Short Circuit, Over Temperature, etc. | |
Rated Power: 3.5/7/11/22KW
Output Current: 16/32/50A
Output Voltage: 220~240V, 380-415V
Connector: CCS1/2, CHAdeMO
Rated Power: 20/30KW
Output Current: 80/125A
Output Voltage: 200~750V, 150-500V
Connector: CCS1/2, CHAdeMO
Rated Power: 90/100/120/160/180/240KW
Output Current: 200A*2
Output Voltage: 200~750V, 150-500V
Connector: CCS1/2, CHAdeMO
Rated Power: 300/360/480KW
Output Current: 200A*2
Output Voltage: 200~750V, 150-500V
Connector: CCS1/2, CHAdeMO
We are a professional battery and charging solution manufacturer since 2002, specializing in environmentally friendly Sealed Lead Acid (SLA) and Lithium batteries. By introducing and developing advanced technology, we adopt world-class production equipment and testing measures to ensure long product life and high energy density.
As a high-tech enterprise, we maintain multiple manufacturing bases and employ approximately 2,000 staff members, including experienced professors and over 50 research engineers. Our independently developed technologies meet and exceed international standards, securing numerous national and international patents.
