DC fast charging station for e-bus is a robust solution for commercial public areas, fulfilling EV energy needs in short durations. Equipped with built-in OCPP 1.6J, the unit allows for seamless remote control. It supports multiple standards including CHAdeMO, CCS Combo 1, CCS Combo 2, and GB/T, ensuring compatibility with all EV brands. Smart power sharing enables simultaneous charging of two electric vehicles.
Plug and play connectors to meet all EV requirements. Custom DC output cables available upon request.
High-speed charging designed for modern fast-paced life, allowing full charges during a short break.
Scalable power options from 120kW up to 300kW by adding or removing power modules.
7-inch colored LCD touch screen with multi-language intelligent human-machine interface.
| MODEL | 60KW | 120KW | 180KW |
|---|---|---|---|
| Nominal Input Voltage | 380 VAC ± 15% | ||
| Acceptable Range | 3-phase, 3ph + N + PE | ||
| Maximum Input Current | 100A | 260A | 300A |
| Output Voltage Range | 200~750VDC (Constant power 600~750VDC) | ||
| Efficiency | > 94% | ||
| Protection Rate | IP54 | ||
| Operating Temp | -25°C to 50°C | ||
| Net Weight (kgs) | 275 | 310 | 328 |
1. Exhaust Vents: Optimized for high-efficiency heat dissipation.
2. Modular System: Includes control, power source, and distribution systems.
3. Emergency Protection: Instant stop button for unexpected incidents.
Equipped with advanced research institutions and professional technical teams, we provide high-quality charging equipment that is safe, efficient, and stable. Our capabilities include OEM and ODM services for the global market, focusing on everything from residential wallboxes to high-power public commercial charging stations.
